• Stable cutting point position keep the orientation fixed at all times.
• Easy to ser & Adjust diameters, avoids operator fatigue.
• Offset and enter, then bring tool to center line for machining.
• Offset & Retract. Leaves no return line marks.
• Excellent size consistency.
• Excellent geometrical accuracies of holes are achieved like borr ovality, taper, surface roughness.
• Suitable for machining center and SPMs.
|
• Best results are obtained for l/d - 2:1
•For more than 3 but up to 7, boring tools in heavy metal are made to order.
• Please provide 5mm extra boring tool length for over travel and to prevent accidental tool dashing the component.
• Ground Inserts will give better size consistency, Ovality and better tool life between two size adjustments.
• PCD ( Poly crystalline Diamond ) Inserts are recommended for machining aluminium & other non - ferrous materials.
•Through coolant hole can also be provided if desired at extra cost.
|
